Rapi-X96

Compact Nucleic Acid Extraction System
Rapi-X96

Overview

Rapi-X96 Automated Nucleic Acid Extraction System is based on magnetic bead based separation technology. 96-deep well plates and different reagents are utilized which are suitable for purification of various clinical sample including blood/tissue/viruses/cells. It maintains temperature uniformity with accurate controls. The instrument uses the special magnetic rods to absorb, transfer and release magnetic beads, so as to purify high quality nucleic acid.

Rapi-X96 Automated Nucleic Acid Extraction System is based on magnetic bead based separation technology. 96-deep well plates and different reagents are utilized which are suitable for purification of various clinical sample including blood/tissue/viruses/cells.

Features

  • The instrument has 4 plate positions, 2 plate positions are heated as standard, pre-heating system
  • UV sterilization device and Level 11 HEPA high efficiency air filter screen effectively eliminate aerosol pollution
  • Rapi-X 96 Automated Nucleic Acid Extraction System adopts magnetic bead separation technology.
  • Through the separation of the magnetic rods and the disposable magnetic rod tip combs, the magnetic rods are transferred between the deep hole plates containing specific reagents to realize the collection, release, transfer and incubation of the magnetic beads.

Fast & Fully Automated Nucleic Acid Extraction System

PC Operation

Ready to use pre-filled Kits available

Automated Efficiency

Applications

High Throughput

96 samples can be extracted within 15-30 mins based on kit & application

10 inch Large Display

Simple interface & easy operation

Light Weight

Saves laboratory space

Open Platform

for all other available automation friendly magnetic bead based kits

Specifications

Model No. Rapi-X96
Sample throughput: 1 - 96
Processing Volume: 50µL - 1000µL
Processing time: 50µL - 1000µL
Elution Volume: 50µL - 1000µL
Temperature control: 4 - 105°C
Module station: 4,2 heatable
Magnetic bead recovery: ≥98%
Program storage: Store > 500 group of program
Operation interface: 10” 1024 X 600 color screen
Network communication: Ethernet Remote Control
Operating temperature range: 5°C - 40°C
Operating humidity range: Less than 80%
Expand interface: USB interface, RS232 interface
Pollution control: UV sterilization, Level 11 HEPA
Dimension: 510mm (L) X 430mm (W) X 470mm (H)
Weight: 27kg [± 0.5kg]
Compatibility: Open platform, maximum compatibility with magnetic bead kit
Power Supply: AC 100-240 Vac, 50/60Hz

Ordering Information

Cat No.

Commercial Name

G2MI80001

RapiX-96 - Automated Nucleic Acid Extraction System

G2MI80002

RapiX-16 - Automated Nucleic Acid Extraction System
